Orbi Bridge Mode – How to Enable AP Mode on Orbi Router

​ ​ ​ ​Orbi Bridge Mode (also called Access Point Mode) allows your Orbi router to work alongside another router without creating network conflicts. This is especially useful if your Internet Service Provider (ISP) modem already has routing enabled.

Enabling Bridge Mode helps prevent Double NAT issues and ensures smooth internet performance across your home.

What Is Orbi Bridge Mode?

When Bridge Mode (AP Mode) is enabled, your Orbi router:

• Stops performing routing functions
• Uses your main modem/router to assign IP addresses
• Acts purely as a WiFi access point
• Eliminates Double NAT conflicts

This setup is ideal if you want to expand WiFi coverage while keeping your existing modem/router as the primary network controller.

When Should You Use Orbi Bridge Mode?

• Your ISP modem has built-in WiFi and routing enabled
• You are experiencing Double NAT errors
• Online gaming shows NAT Type issues
• Port forwarding is not working properly

How to Enable Orbi Bridge Mode

Step 1: Connect to Orbi Network

Ensure your computer or mobile device is connected to the Orbi WiFi network.

Step 2: Access the Login Page

Open a web browser and type:

• http://orbilogin.com
• http://192.168.1.1

Enter your admin username and password.

Step 3: Go to Advanced Settings

Navigate to:

Advanced > Advanced Setup > Router / AP Mode

Step 4: Select AP Mode

Choose AP Mode (Access Point Mode) and click Apply.

Your Orbi router will reboot automatically.

Important Notes After Enabling Bridge Mode

• Orbi will no longer manage IP addresses.
• Parental controls and certain advanced features may be limited.
• All routing functions will be handled by your main modem/router.

How to Disable Bridge Mode

If you want to switch back to router mode:

1. Log in to the Orbi admin page.
2. Go to Advanced > Advanced Setup > Router / AP Mode.
3. Select Router Mode.
4. Click Apply and allow the router to reboot.

Benefits of Using Orbi in Bridge Mode

• Eliminates Double NAT problems
• Improves network compatibility
• Simplifies advanced configurations
• Enhances overall network stability

Conclusion

Orbi Bridge Mode is a powerful feature that allows your mesh system to function seamlessly with an existing router. If you are facing NAT issues or router conflicts, enabling AP Mode can significantly improve network performance and stability.

Always ensure proper configuration to avoid connectivity interruptions.
